885B-II

• ROPS/FOPS open cab with:
• Adjustable suspension vinyl seat, with a 50.8 mm (2”) seatbelt
• Adjustable operator console
• Pedal accelerator
• Manual accelerator
• Front windshield wiper with washer
• Safety glass
• Ceiling light
• Internal and external rear-view mirrors
• 12 V (*) power supply
• Automatic master switch
• Steps on the right and left sides

(*) Only available in closed cabins

• 845B FPT F4HE9687W
• 865B FPT F4HE9687C
• 885B FPT F4HE9687K
• Turbocharged, diesel
• Dry air filter with primary and secondary safety elements
• Air pre-filter with cyclonic dust ejector
• 80 A alternator
• Swing-up hood, diesel

• Hydraulic system with load sensor, closed center
• 9-section control valve
• Hydraulic control for all functions: blade lifting (right and left side), circle turn, side shift of the circle, wheel lean, frame articulation, blade side shift and pitch, front and rear accessories
• Diagnostics center with 8 quick couplers
• Hydraulic axial piston pump
• Hydraulic engine fan

• Multidisk oil-bathed service brakes with nitrogen accumulator safety system
• Disk parking brake integrated into the transmission with warning light

• 14” 3-pieces rim / 17,25 x 25 - 12L - G2 tubeless

• Standard tool kit
• Drawbar / Standard circle

• Conventional differential with brakes on 4 wheels and differential locking with electrohydraulic mechanism (rear axle)

Hydrostatic steering with integrated emergency system

• Electronic Information Center
• Indicators/gauges:
• Tachometer
• Direction selected F/N/R
• Transmission modes - automatic/manual
• Selected gear
• Engine cooling temperature
• Fuel level
• Transmission oil temperature
• Hydraulic oil temperature
• Hourmeter
• Fuel consumption
• Engine diagnostics
• Transmission diagnostics

• Low fuel level
• Floodlights
• High beam
• Brake pressure
• Main alert
• Parking brake

• Warning alert
• Emergency alert
• Reversing alert

• Lights
• Front headlight with direction indicators (2)
• Rear brake light and direction indicators (2)
• Rear work light on top of the cabin (2)
• Front work light on top of the cabin (2)
• 24 V system (Two 12 V batteries 12 V / 750 CCA)
• Electronic system monitoring
• Horn
• Hourmeter
• Reverse alarm

• ZF transmission of torque conversion type with lock up (also functions as Direct Drive), Powershift, 6 forward speeds and 3 reverse speeds, automatic gear shift, emergency electrical failure device (Limp-Home)
• All ROPS/FOPS cabins are certified in accordance with the SAE J1040 (ROPS) and SAE J231 (FOPS) standards.

• Closed high cab (fixed front window)
• Closed high cab (front flip-down window)
• Sunshade(front and rear)

• Air conditioner for closed cab
• Fire extinguisher
• Windshield washer and lower windshield wipers
• Rear windshield washer and wipers
• Radio
• Tandem lock device
• Rear fogger

• Drawbar / Heavy Duty circle

• Dozer Blade
• Push plate
• 5 tooth front scarifier
• 6 additional teeth for the front ripper
• Dozer blade float electrovalve
• Front counter weight
• Lighting on dozer blade

• 3,658 x 622 x 22 mm blade
• 3,962 x 671 x 22 mm blade
• 4,267 x 671 x 22 mm blade
  –304.8 mm right blade extension
  –304.8 mm left blade extension

• Medium ripper with 3 large teeth and 5 small teeth
• 2 additional large teeth and 4 additional small teeth
• Rear pull hook
• Support for lifting the machine

• 2 work lights behind the blade
• 2 work lights mounted in front of the moldboard
• 2 work lights on the front attachment

• Moldboard lifting cylinder lock valve
• Moldboard float electrovalve (includes the lock valve)
• Anti-shock electrovalve with 2 accumulators for the moldboard
• Anti-shock electrovalve with 3 accumulators for the moldboard and circle

• Extra quality vinyl mechanical suspension seat
• Mechanical suspension fabric seat
• Pneumatic mechanical suspension fabric seat (3”) 76.5 mm seatbelt

• Revolving safety light
• Luxury toolbox
• Toolbox without tools, with support, mounted on the rear frame
• Slow movement symbol
• Electric pump for filling tires
• Support for spare tire

• 9’’ Rim - single piece/14x24 tire-12L-G2
• 10” Rim - 3 pieces / 14x24 tire - 12L - G2
• 13” Rim - single piece / 17.5x25 tire - 12L - L2
• 14” Rim - 3 pieces / 17.5x25 tire - 16L - L3

• 9” Rim - single piece / 14x24 tire - 12L - G2
• 10” Rim - 3 pieces / 14x24 tire - 12L - G2

• 9” Rim - single piece / 14x24 tire - 12L - L2
• XGLA2 RADIAL
• 10” Rim - 3 piece / 14x24 tire - 12L - L2
• XGLA2 RADIAL

• 9” Rim - single piece with valve
• 10” Rim - 3 pieces with valve
• 13” Rim - single piece with valve
• 14” Rim - 3 pieces with valve

*All the options are subject to the local availability.
