845B

• ROPS/FOPS open cab with:
  - Adjustable suspension vinyl seat, with a 50.8 mm (2”) seatbelt
  - Adjustable operator console
• Pedal accelerator
• Manual accelerator
• Front windshield wiper with washer
• Safety glass
• Ceiling light
• Internal and external rear-view mirrors
• 12 V(*) power supply (Only available in closed cabins)
• Automatic master switch
• Steps on the right and left sides
  (*) Only available in closed cabins

• Turbocharged, diesel
• Dry air filter with primary and secondary safety elements
• Air pre-filter with cyclonic dust ejector
• Alternator
• Swing-up hood

• Hydraulic system with load sensor, closed center
• 9-section control valve
• Hydraulic control for all functions: blade lifting (right and left side), circle turn, side shift of the circle, wheel lean, frame articulation, blade side shift and pitch, front and rear accessories
• Diagnostics center with 8 quick couplers
• Movable saddle with 5 service positions and hydraulic lock
• Blade
• Hydraulic axial piston pump
• Hydraulic engine fan

• Multidisk oil-bathed service brakes with nitrogen accumulator safety system
• Disk parking brake integrated into the transmission with warning light

• 9” single piece rim / 14 x 24 - 12L - G2 tubeless

• Drawbar / Standard circle

• 845B VHP - “Limited Slip” torque differential (anti-skid system)
• 865B VHP - “Differential lock” torque differential

• Hydrostatic steering with integrated emergency system

• Electronic Information Center
  Indicators/gauges:
• Tachometer
• Direction selected F/N/R
• Transmission modes - automatic/manual
• Selected gear
• Engine cooling temperature
• Fuel level
• Transmission oil temperature
• Hydraulic oil temperature
• Hourmeter
• Fuel consumption Engine
• Diagnostics DeClutch activation indicator
• Transmission diagnostics

• Low fuel level
• Floodlights
• High beam
• Brake pressure
• Main alert
• Parking brake

• Warning alert
• Emergency alert
• Reversing alert

• Front headlight with direction indicators (2)
• Rear brake light and direction indicators (2)
• Rear work light on top of the cabin (2)
• Front work light on top of the cabin (2)
• 24 V system (Two 12 V batteries 12 V / 750 CCA)
• Electronic system monitoring
• Horn
• Hourmeter
• Reverse alarm

Transmission

• ZF transmission of torque conversion type with lock up (also functions as Direct Drive)
• Powershift, 6 forward speeds and 3 reverse speeds, automatic gear shift, emergency electrical failure device (Limp-Home)

All ROPS/FOPS cabins are certified in accordance with the SAE J1040 (ROPS) and SAE J231 (FOPS) standards.

• Closed high cab (fixed front window)
• Closed high cab (front flip-down window)
• Closed low cab (fixed front window)
• Closed low cab (front flip-down window)

• Ventilation box for closed cab
• Heater for closed cab
• Air conditioner for closed cab
• Acoustic insulation for closed cab
• Fire extinguisher
• Windshield washer and lower windshield wipers
• Rear windshield washer and wipers
• Radio
• Tandem lock device
• Rear fogger

• Drawbar / Heavy Duty circle

• Dozer Blade
• Push plate
• 5 tooth front scarifier
• 6 additional teeth for the front ripper
• Dozer blade float electrovalve
• Front counter weight

• 3,658 x 622 x 22 mm blade
• 3,962 x 671 x 22 mm blade
• 4,267 x 671 x 22 mm blade
  - 304.8 mm right blade extension
  - 304.8 mm left blade extension
• Heavy Duty cutting edge - extra

• Type: Front mounted
• Cutting width: 1.168 mm
• Teeth: 5 (optionally, 11)
• Spacing between teeth: 229 mm (114 mm, optional)
• Lift above ground: 527 mm
• Maximum Penetration: 318 mm
• Weight: 570 kg

• Ripper with 5 teeth for 845B VHP
• Ripper 3 teeth and Sacrifier 5 teeth for models 845B VHP and 856B VHP
• Additional teeth (2 for ripper + 4 scarifier)
• Rear pull hook
• Support for lifting the machine

• 2 work lights behind the blade
• 2 work lights mounted in front of the moldboard
• 2 work lights on the front attachment

• Moldboard lifting cylinder lock valve
• Moldboard f oat electrovalve (includes the lock valve)
• Anti-shock electrovalve with 2 accumulators for the moldboard
• Anti-shock electrovalve with 3 accumulators for the moldboard and circle

• Extra quality vinyl mechanical
• Suspension seat
• Mechanical suspension fabric seat
• Pneumatic mechanical suspension
• Fabric seat 3”
• 76.5 mm seatbelt

• Revolving safety light
• Luxury toolbox
• Toolbox without tools, with support, mounted on the rear frame
• Slow movement symbol
• Electric pump for fi lling tires
• Support for spare tire

• Type: Parallelogram
• Cutting width: 2.185 mm
• Ripper teeth: 5
• Lift above ground 505 mm
• Maximum penetration 350 mm
• Weight: 640 kg

• 10” Rim - 3 piece / 14x24 tire - 12L - G2
• 13” Rim - single piece / 17.5x25 tire - 12L - L2
• 14” Rim - 3 piece / 17.5x25 tire - 12L - L2
• 14” Rim - 3 piece / 17.5x25 tire - 16L - L3

TIRES WITH TUBES

• 9” Rim - single piece / 14x24 tire - 12L - G2
• 10” Rim - 3 pieces / 14x24 tire - 12L - G2

RADIAL TUBELESS TIRES

• 9” Rim - single piece / 14x24 tire - 12L - L2
  XGLA2 RADIAL
• 10” Rim - 3 piece / 14x24 tire - 12L - L2
  XGLA2 RADIAL

RIMS

• 9” Rim - single piece with valve
• 13” Rim - single piece with valve
• 10” Rim - 3 piece with valve
• 14” Rim - 3 piece with valve

• Type: Front mounted
• Width: 2.762 mm
• Height: 953 mm
• Lift above ground: 622 mm
• Penetration: 165 mm
• Weight: 1.165 kg

• Type: Parallelogram
• Cutting width: 2.185 mm
• Teeth base: ripper 3 + scarifier 5
• Teeth additional: ripper 2 + scarifier 4
• Lift above ground
• Ripper teeth: 518 mm
• Scarifier teeth: 703 mm
• Maximum penetration
• Ripper teeth: 437 mm
• Scarifier teeth: 252 mm
• Weight: 795 kg (845B)
• Weight: 850 kg (865B)
