845C
The CASE 845C Motor Grader is a product of advanced engineering, ensuring consistent power delivery with two distinct power curves, thanks to its FPT Engine. Prioritizing safety and ease, it offers ground-level access for all main checks, making maintenance a breeze. Its versatility is showcased with a wide range of tailored options, making it suitable for various grading applications. Features like the rear-mounted cab and load-sensing hydraulic system set it apart from other graders, giving it superior efficiency and productivity.
Download Brochures
Share or download a brochure for additional information.
Solutions
CASE Care
Our extended service support, decreases downtime, maximizes productivity and gets you the additional peace of mind you deserve.
CASE Protect
Extended warranty support and ensures optimum performance of your machine, round-the-clock availability of expert technicians and hassle-free operations.
CASE SiteWatch™
Boost your machine's profitability by tracking and managing your fleet's operation.
Standard Equipment
- Adjustable suspension vinyl seat, with a 50.8 mm (2”) seatbelt
- Adjustable operator console
- Pedal accelerator
- Manual accelerator
- Front windshield wiper with washer
- Safety glass
- Ceiling light
- Internal and external rear-view mirrors
- 12 V (*) power supply
- Automatic master switch
- Steps on the right and left sides
(*) Only available in closed cabins
- FPT / F4HE613B*W002
- Turbocharged, diesel
- Dry air filter with primary and secondary safety elements
- Air pre-filter with cyclonic dust ejector
- 90 A alternator
- Swing-up hood, diesel
- Hydraulic system with load sensor, closed center 9-section control valve
- Hydraulic control for all functions: blade lifting (right and left side), circle turn, side shift of the circle, wheel lean, frame articulation, blade side shift and pitch, front and rear accessories
- Diagnostics center with 8 quick couplers
- Hydraulic axial piston pump
- Hydraulic engine fan
- Multidisk oil-bathed service brakes with nitrogen accumulator safety system
- Disk parking brake integrated into the transmission with warning light
- 9" Single piece rim / 14 x 24
- Standard tool kit
- Drawbar / Standard circle
- Conventional differential with brakes on 4 wheels and differential locking with electrohydraulic mechanism (rear axle)
- Hydrostatic steering with integrated emergency system
- Electronic Information Center
- Indicators/gauges:
- Tachometer
- Direction selected F/N/R
- Transmission modes - automatic/manual
- Selected gear
- Engine cooling temperature
- Fuel level
- Transmission oil temperature
- Hydraulic oil temperature
- Hourmeter
- Fuel consumption
- Engine diagnostics
- Transmission diagnostics
- Low fuel level
- Floodlights
- High beam
- Brake pressure
- Main alert
- Parking brake
- Warning alert
- Emergency alert
- Reversing alert
- Lights
- Front headlight with direction indicators (2)
- Rear brake light and direction indicators (2)
- Rear work light on top of the cabin (2)
- Front work light on top of the cabin (2)
- 24 V system (Two 12 V batteries 12 V / 750 CCA)
- Electronic system monitoring
- Horn
- Hourmeter
- Reverse alarm
- ZF transmission of torque conversion type with lock up (also functions as Direct Drive), Powershift, 6 forward speeds and 3 reverse speeds, automatic gear shift, emergency electrical failure device (Limp-Home)
All ROPS/FOPS cabins are certified in accordance with the SAE J1040 (ROPS) and SAE J231 (FOPS) standards.
Optional Equipment
- Air conditioner for closed cab
- Fire extinguisher
- Windshield washer and lower windshield wipers
- Rear windshield washer and wipers
- Radio
- Tandem lock device
- Rear fogger
- Drawbar / Heavy Duty circle
- Front counter weight
- Lighting on dozer blade
- 3,658 x 671 x 22 mm blade
- 3,962 x 671 x 22 mm blade
- 4,267 x 671 x 22 mm blade
–304.8 mm right blade extension
–304.8 mm left blade extension
- Medium ripper with 3 large teeth and 5 small teeth
- 2 additional large teeth and 4 additional small teeth
- Rear pull hook
- Support for lifting the machine
- 2 work lights behind the blade
- 2 work lights mounted in front of the moldboard
- 2 work lights on the front attachment
- Revolving safety light
- Luxury toolbox
- Toolbox without tools, with support, mounted on the rear frame
- Slow movement symbol
- Electric pump for filling tires
- Support for spare tire
- 10” Rim - 3 pieces / 14x24 tire
- 14” Rim - 3 pieces / 17.5x25 tire
RADIAL TUBELESS TIRES
- 9” Rim - single piece / 14x24 tire
XGLA2 RADIAL
Compare Specifications
ENGINE | ||
Make / Model | ||
Type | ||
Cylinders | ||
Bore/Stroke | ||
Displacement | ||
Horsepower at 2200 rpm Gross (SAE J1995 Gross) - Low Curve | ||
Horsepower at 2200 rpm Gross (SAE J1995 Gross) - High Curve | ||
Horsepower at 2200 rpm Gross (SAE J1995 Gross) - Mid Curve | ||
Horsepower at 2200 rpm Net (SAE J1349) - Low Curve | ||
Horsepower at 2200 rpm Net (SAE J1349) - Mid Curve | ||
Horsepower at 2200 rpm Net (SAE J1349) - High Curve | ||
maximum torque at 1500 rpm gross (sae j1995 gross) - Low Curve | ||
Maximum torque at 1500 rpm Gross (SAE J1995 Gross) - Mid Curve | ||
Maximum torque at 1500 rpm Gross (SAE J1995 Gross) - High Curve | ||
Maximum torque at 1500 rpm Net (SAE J1349) - Low Curve | ||
Maximum torque at 1500 rpm Net (SAE J1349) - High Curve | ||
POWERTRAIN | ||
SYSTEM | ||
ELECTRICAL SYSTEM | ||
BLADE/MOLDBOARD | ||
STEERING | ||
ARTICULATION | ||
CAPACITIES (REFILL) | ||
SADDLE | ||
FRAME | ||
DRAWBAR | ||
CIRCLE | ||
REAR RIPPER | ||
FRONT SCARIFIER |
