SPECIFICATIONS
GENERAL DIMENSIONS
LOADER SPEED
Raising time (loaded)
5.2 sec
Dump time (loaded)
1.2 sec
Lowering time (empty, power down)
2.5 sec
Lowering time (empty, float down)
2.4 sec
Z-BAR BUCKETS
XR BUCKETS
(EXTRA REACH)
XT BUCKETS
(PARALLEL
LIFT)
721F
2.7 m
3
2.4 m
3
w/QC
2.7 m
3
2.4 m
3
w/QC
2.4 m
3
w/QC
Bucket with bolt on:
edge teeth edge teeth edge teeth edge teeth edge teeth
Bucket volume (heaped)
m
3
2.7 2.7 2.4 2.4 2.7 2.7 2.4 2.4 2.4 2.4
Bucket Payload
kg 5440 5369 5299 5325 4533 4464 4385 4409 4924 4946
Maximum material density
ton/m
3
2.0 2.0 2.2 2.2 1.7 1.7 1.8 1.8 2.1 2.1
Bucket outside width
m 2.73 2.73 2.47 2.47 2.73 2.73 2.47 2.47 2.47 2.47
Bucket weight
kg 1237 1344 1656 1619 1237 1344 1656 1619 1627 1590
Tipping load - straight
kg 12435 12292 11356 11405 10419 10280 10129 10177 11280 11326
Tipping load - Articulated at 40°
kg 10881 10738 10599 10649 9066 8927 8770 8818 9847 9893
Breakout force
kg 14236 12885 12185 11284 14160 12817 12040 11151 12016 11193
Lift capacity from ground
kg 13607 13480 13419 13462 11302 11177 11072 11115 13096 13111
A Dump height at 45° at full height
m 2.93 2.86 2.82 2.74 3.33 3.26 3.21 3.14 2.77 2.69
B
Hinge pin height
m 3.98 3.98 3.98 3.98 4.37 4.37 4.37 4.37 4.16 4.16
C
Overall height
m 5.52 5.52 5.51 5.51 5.91 5.91 5.90 5.90 5.67 5.66
D
Bucket reach at full height
m 1.13 1.21 1.28 1.36 1.13 1.21 1.28 1.36 1.27 1.36
E
Dig depth
cm 7.4 7.4 6.2 6.7 7.6
7.7 6.5 6.9
21 21.3
Overall length without bucket
m 6.53 6.53 6.53 6.53 6.85 6.85 6.85 6.85 6.52 6.52
L
Overall length with bucket on the ground
m 7.65 7.76 7.83 7.95 7.65 7.76 8.18 8.30 8.12 8.24
R
Turning radius to front corner of the bucket
m 6.3 6.4 6.3 6.3 6.5 6.5 6.5 6.5 6.2 6.3
Bucket rollback in carry position
°
43
43
38
38
41
41
36
36
58
58
Dump angle at full height
°
55
55
61
61
55
55
61
61
54
54
Machine operating weight
kg 14225 14532 14844 14807 14644 14751 15063 15026 14915 14878
Note: bucket specification can slightly differ according to plant source. More bucket choice is available, please contact your local dealer.
